Sansui AU-717 Integrated Amplifier Repair & Restoration

I recently restored a gorgeous Sansui AU-717 integrated amplifier. This AU-717 was not running properly and was in serious need of some TLC.

The Sansui AU-717 integrated amplifier is one of those pieces that I just love working on. Sansui designed and built the AU-717 at a time when labour was cheaper. Money went into build quality, parts and layout.

This amplifier is an integrated model, meaning it has a preamplifier and power amplifier in the same chassis. The pre and power sections can be separated if necessary and the whole piece is extremely well laid out.

Anyway, This AU-717 was another victim of the Sansui ‘corrosive glue’ problem, more on that later.

Specifications (Courtesy of the HiFi Engine)

Power output: 85 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.025%
Damping factor: 60
Input sensitivity: 2.5mV (MM), 150mV (line)
Signal to noise ratio: 78dB (MM), 100dB (line)
Channel separation: 60dB (MM), 65dB (line)
Output: 150mV (line), 1V (Pre out)
Speaker load impedance: 8Ω (minimum)
Dimensions: 430 x 168 x 389mm
Weight: 17.8kg
Year: 1978 – 1980


The weight of this amplifier is amazing for something that was not even top of the Sansui range at the time. Sansui laid out their equipment beautifully in terms of ease of servicing and sparing little expense. The amplifier contains a really nice dual-mono phono preamplifier, with selectable gain and lots of styroseal capacitors. The phono preamplifier sits in a separate shielded box, which is a sound way to reduce noise in sensitive high-gain circuits.

This beast has two separate power transformers – serious in a mid-range integrated amp, and almost unheard of now. And let’s not forget something I tell customers all the time: there is nothing new in amplification. No new inventions have furthered the field and you can buy something like this with great confidence, though like this one, it’s likely to need a decent service and maybe even a few new parts.

Cosmetically I have thoroughly cleaned the insides of the AU-717 and you could literally eat out of this beast now. I ordered a new protection relay as the relay was faulty in this example. I also spent some time cleaning potentiometers, trimmer pots and controls and tweaking bias and offset in the output modules.


What follows are some pictures, with captions, detailing the work and the various stages needed to get the old Sansui Au-717 back up and running again.

Here is the gorgeous Sansui AU-717, with most of her clothes still on.
All these shots are of the amplifier prior to using the cleaning method I’ve developed
Dust, dirt and years of built-up crud are sitting on every part of this lovely old girl…
Capacitors, held to the board  by corrosive glue, dirt, along with dust and other contaminants. This amplifier will never function correctly until all of this is gone.
Some main filter capacitors and you can see the output modules and their heat-sinks to the bottom of the picture.
Close-up of the dirty regulator board, dual-transformers and filter capacitors

These shots are after are after a very thorough cleaning, using a system I’ve developed for chassis-level cleaning during restorations.

Much cleaner already – the difference is night and day.
Detail shot of those gorgeous dual transformers and filter capacitor array, now sparkly clean.
Here, you see the original capacitors, located on the regulator board where I found a lot of this amplifier’s problems.


Parts Replacement & Corrosive Glue

A large part of the restoration involved replacing aged electrolytic capacitors and removing the Sansui corrosive glue from each circuit board. I worked one board at a time, meticulously cleaning them, removing the old caps, cleaning away the corrosive glue, replacing any affected parts, installing new capacitors and flux cleaning.

Corrosive glue and leaking capacitors have caused this PSU/protection board to need major repair.
This speaker protection relay was playing up on this particular AU-717.
Out with the old, on the right, in with the new, on the left. The replacement relay has extra terminals, but these are not needed and don’t affect operation.
The repaired and restored power supply / protection board. The new relay is at the bottom of the board.
Another view of the repaired power supply and protection board.
Here’s the chassis, with one output module removed for servicing.
View of an output board, prior to removal of capacitors and cleaning.
Another, closer view. These capacitors will all be removed, the board cleaned and then new capacitors installed.
Here we have one of the two output boards, with capacitors removed, prior to cleaning. Every trace of the ‘corrosive glue’ must be removed.
Restored output amplifier board
Another view of a restored amplifier board…
…and another
Cleaned and restored boards back in the chassis.
Ready for final inspection and adjustment of bias and DC offset.
